[eptar] Reinforcement
English - German - Hungarian | ArchiCAD 15-18 | Win-Mac

New 1.35

This solution helps designers to draw documents and lists the necessary reinforcement for their buildings in ArchiCAD. The application provides tools to define all 2D drawings as well as complete 3D models.

Our simple solution contains a library of reinforcement objects and an Add-on. They provide great freedom in defining constructions and also help to specify complex objects. What?s more, Eptar Reinforcement checks the rebar ID numbering and corrects it if necessary. With our tool, users can simply calculate the necessary amount of rebars. Iron list is available on the floor plan just as the interactive schedule.

Overview of the features:

  • most used rebar and stirrup forms are preset, but custom polygonal forms can be set too
  • steel elements can be rotated, thus more difficult constructions (e.g. stairs) can be modeled
  • rebars and steel meshes can automatically be placed with the help of ArchiCAD "Accessories" Add-on
  • complex elements (columns, beams and crownings) can be defined
  • many view and display options
  • cutting list generation
  • automatic correction of enumeration
  • changes can easily be made on the layout and in the Object Settings window as well


The Eptar Reinforcement solution runs in Demo mode unless you buy and sign up for the product.

Supported versions:
- ArchiCAD 18
- ArchiCAD 17
- ArchiCAD 16
- ArchiCAD 15

The solution works only in Demo mode in ArchiCAD EDUCATION version. Demo mode functions as the full version but the amount of rebars, used to define complex elements and make listing, is limited.


Attention! The full version operates with legal ArchiCAD versions only. The full version of Reinforcement does not operate with any other ArchiCAD versions (Demo, Educational, cracked).


Updates information   04.11.2014.


[?pt÷r] Reinforcement solution
Overview of Main Features
1.3 DEMO version Full version 1.3 Full version 1.21
preset common rebars and stirrups + + +
custom polygonal rebar forms + + +
rebars can be rotated in space + + +
automatic array of meshes and bars + + +
complex element:
unlimited use of columns
- + +
complex element:
unlimited use of beams
- + +
complex element:
unlimited use of crownings
- + +
unlimited rebar placement - + +
making automatic cutting list - + +
more layout display options + + +
displaying views on the floor plan + + +
exporting list into TXT + + +
exact display of rebar bending in 3D + + -
dimension unit choice + + -
global display settings (2D, 3D, labels and texts) + + -
custom text settings + + -
new display options + + -
intelligent markers + + -
new stirrup types + + -
label option for views + + -
custom label texts + + -
399 €



This application will work in demo mode
until you do not buy and register it!
