Supported ArchiCAD versions | Version 3.1 | Version 3.0 | Version 2.1 | |||||
---|---|---|---|---|---|---|---|---|
ArchiCAD 24 | ||||||||
ArchiCAD 23 | ||||||||
ArchiCAD 22 |
Reinforcement main features | Version 3.1 | Version 3.0 | Version 2.1 | Demo version | |||
---|---|---|---|---|---|---|---|
Archicad 24 compatibility | |||||||
Automatic Reinforcement of CURVED walls | |||||||
Automatic Reinforcement of SLANTED walls | |||||||
Reinforcement wreaths and edges on slabs | |||||||
Shear rebar placement for slab cutouts corners | |||||||
Updated user interface | |||||||
Automatic reinforcement of roofs with mesh or rebar tool | |||||||
Several roof plains are now reinfoceable at the same time | |||||||
Automatic reinfocement of complex roofs | |||||||
A floating palette that can be placed likely | |||||||
Automatic reinforcement of walls | |||||||
Several walls or slabs can be reinforced with a single selection | |||||||
Multiple layers of rebar can be placed at a time | |||||||
Placement of upturned or folded mesh | |||||||
Distributable rebars along the curve | |||||||
New rebar object which linear meter can be adjusted in kg/m | |||||||
Adjustable value of concrete cover in case of top or button reinforcement | |||||||
The different length rebars can be displayed separately in the cutting list | |||||||
In case of mesh, the multidirectional rebars can be listed separately | |||||||
In case of circle cross-section the radius of the stirrup is displayed in the list | |||||||
The value of the joint length is displayed in the list | |||||||
exact display of rebar bending in 3D | |||||||
dimension unit choice | |||||||
global display settings (2D, 3D, labels and texts) | |||||||
intelligent markers | |||||||
new stirrup types | |||||||
label option for views | |||||||
custom label texts | |||||||
preset common rebars and stirrups | |||||||
custom polygonal rebar forms | |||||||
rebars can be rotated in space | |||||||
automatic array of meshes and bars | |||||||
complex element: unlimited use of columns |
|||||||
complex element: unlimited use of beams |
|||||||
complex element: unlimited use of crownings |
|||||||
unlimited rebar placement | |||||||
making automatic cutting list | |||||||
more layout display options | |||||||
displaying views on the floor plan | |||||||
exporting list into TXT |
