   Layer structure editor

With the help of the onine layer structure editor you can assemble a multi-component layer structure (wall, pillar, beam, ceiling, roof, filling) that can be inserted into an architectural design software. This insertion means complete functionality: the inserted object follows the set parameters, shows up on the layout as a building panel in 2D and 3D as well. It is possible to create a formatted, exact list which includes the given building structures every component with the product name shown or hidden.

The layer structure can be assembled and modified here. During the editing we can monitor the changes in the structure's thermal values too. An XML file can be saved from the assembled layer structure which can be opened in CAD design softwares with the help of the layer structure editor applivation. After this the defined building structure is created automatically in a displayable and listable fashion.

Layer structure editor

Layer structure editor

Online apply's User guide Introduction   The solution was
developed by Éptár Kft.
